Single Side PCB
Single sided printed circuit boards are circuit boards with one layer of conducting material on one side of the board, while the other side is used for incorporating different electronic components.
A single sided board is made of a substrate layer, a conductive metal layer and followed by a protective solder mask and silk screen. Single sided circuit boards were the first printed circuit board technology and have been in circulation since the 1950s, and remain one of the most commonly used circuit boards due to their simple design.
Capability
Base material:Aluminum/Copper/Iron Alloy
Thermal Conductivity (dielectrial layer): 0.8, 1.0, 1.5, 2.0, 3.0 W/m.K.
Board Thickness: 0.5mm~3.0mm(0.02"~0.12")
Copper thickness: 0.5 OZ, 1.0 OZ, 2.0 OZ, 3.0 OZ.
Outline: Routing, punching, V-Cut
Soldermask: White/Black/Blue/Green/Red Oil
Legend/Silkscreen Color: Black/White
Surface finishing: Immersion Gold, HASL,ROHS
Max Panel size: 200*400mm
Packing: Vacuum/Plastic bag
Samples L/T: 4~6 Days
MP L/T: 5~7 Days
Double Side PCB
Double sided PCBs are a popular choice in the industry when it comes to printed circuit boards, as they allow for more complex designs, circuits and thus benefits for products. Unlike single sided PCBs, double sided PCBs can mount the conductive copper and components on both sides of the board, as opposed to just the one. These double sided boards allow for closer routing traces as they can alternate between the top and bottom layers using vias. This can be very useful in many electronic products as the circuits on one side of the board can be connected to the other with the help of holes drilled onto the board.
Due to how they’re manufactured, double sided PCBs are a great choice thanks to their ease of use and flexibility. They also offer increased circuit density as the second layer means there is more capacity for PCB components than on single sided PCBs.With this increased space, double sided PCBs use a more complex circuitry, meaning they are great for more advanced electronic systems such as lighting and car dashboards. These benefits can also come with a reduction in production cost because double sided boards are often smaller in size than other PCBs..
Capability
Base material:Aluminum/Copper/Iron Alloy
Thermal Conductivity (dielectrial layer): 0.8, 1.0, 1.5, 2.0, 3.0 W/m.K.
Board Thickness: 0.5mm~3.0mm(0.02"~0.12")
Copper thickness: 0.5 OZ, 1.0 OZ, 2.0 OZ, 3.0 OZ.
Outline: Routing, punching, V-Cut
Soldermask: White/Black/Blue/Green/Red Oil
Legend/Silkscreen Color: Black/White
Surface finishing: Immersion Gold, HASL,ROHS
Max Panel size: 200*400mm
Packing: Vacuum/Plastic bag
Samples L/T: 4~6 Days
MP L/T: 5~7 Days
Multilayer PCB
In simple words, Multilayer PCB is a printed circuit board with more than two layers and has a minimum of three conductive layers of conductive material or copper layer. When looking at a multilayer PCB, the top and bottom layers look similar to a double-sided PCB but they have more layers on both sides of the core. These layers are interconnected with copper-plated holes and there can be more layers as we have witnessed up to 40 layers. The active and passive components are placed on the top and bottom layers of the multilayer PCB while the inner stacked layers are used for routing.
Capability
Base material:Aluminum/Copper/Iron Alloy
Thermal Conductivity (dielectrial layer): 0.8, 1.0, 1.5, 2.0, 3.0 W/m.K.
Board Thickness: 0.5mm~3.0mm(0.02"~0.12")
Copper thickness: 0.5 OZ, 1.0 OZ, 2.0 OZ, 3.0 OZ
Outline: Routing, punching, V-Cut
Soldermask: White/Black/Blue/Green/Red Oil
Legend/Silkscreen Color: Black/White
Surface finishing: Immersion Gold, HASL,ROHS
Max Panel size: 200*400mm
Packing: Vacuum/Plastic bag
Samples L/T: 4~6 Days
MP L/T: 5~7 Days
Metalcore PCB
Metal core PCBs find their home in nearly any application where high amounts of heat are generated as the device operates. These boards aren’t a great substitute for ceramics as they are a lower cost option, and they provide higher thermal conductivity to remove heat from important components
Advantage of utilizing Multicore PCB
Excellent heat dissipation
High thermal conductivity: 137W/m.K
Higher reliability with better heat dispatch and small number of solder joint.
Provide enhanced reliability and lifespan of LED
Easy assembly for high powers LEDs
High quality material and production process allows easy assembly and substantial reduce the error percentage in assembly process
Substantially reduced space and cost
With better security protection(difficult to hack using reverse engineering)
Shorter time to the market
Application of Multicore PCB
High Power LED (up to 200W)
LED Backlight for LED TV
LED Front Light for E-Book
Agriculture & Horticulture Lighting
Street & Parking Lot Lighting
Automotive
Power Supply
Customer Electronics Lighting
Other products that require thermal solutions
Overall Evaluation
Our Services
| Feature |
Capability |
| Quality Grade: |
FR4,TG135 LESON |
| Prototype: |
Minimum 4pc |
| Order Quantity: |
100pc - 10,000+pcs |
| Build Time: |
1 - 5 days(ProtoType), 1 - 2 weeks(Production), or scheduled deliveries |
| PCB Spec Requirements: |
PCB whose width/length is less than 50mm should be panelized Max board size: 200x400 mm Board Type: Rigid PCBs, Flexible PCBs,Metal core PCBsSurface finish: lead/lead-free HASL, ENIG, Silver,OSP |
| Assembly Types: |
Surface mountThro-holeMixed technology (SMD & Thru-hole)Single or double sided placement Conformal coating Shield cover assembly for EMI emission control |
| Solder Type: |
Lead , ENIG & Lead-free - RoHS |
| Board Teting via under list of proces: |
BBT and FBT |
| PCB Masking Colour Type's: |
GREEN
RED
BLUE
BLACK
WHITE |
